ClimaRad Ventura V1D

This product is subject to Topsector Energy Subsidy from the Ministry of Economic Affairs.

Continuous product development has resulted in the introduction of the ClimaRad Ventura. This ventilation unit with heat recovery offers everything required to provide rooms with a healthy and comfortable indoor climate. The device is guaranteed to be applicable thanks to multiple connection options to the facade and is highly suitable for facades exposed to noise.

Benefits ClimaRad Ventura V1D

  • 100% applicability thanks to connection options, no parapet required;
  • Financial advantage thanks to the application of Ventura V1D (two rooms with one device);
  • Suitable for facades exposed to noise;
  • Draught-free ventilation guaranteed in high-rise buildings.

The ventilation unit supplies clean air from outside via a duct in the facade. The heat exchanger ensures the filtered outdoor air is preheated when it is blown into the room. Polluted indoor air is filtered and exhausted via the second duct in the outer facade. The reuse of heat by the exchanger provides the user with significant energy savings.

The ventilation unit with heat recovery is equipped with sensors for CO2, humidity, indoor and outdoor temperature and pressure sensors for balance control. They measure the air quality and automatically determine the required ventilation for each room.

This Ventura V1D is equipped with an extra duct to an external room, meaning two adjacent rooms can be simultaneously ventilated using a single unit. This makes it highly suitable for application in high-rise buildings and 2-room apartments. These projects often make use of underfloor heating, which means the Ventura V1D is the right complement in the area of ventilation.

Also have a look at our two other Ventura models: the ClimaRad Ventura V1X and the Ventura V1C.

Summer night ventilation

The ClimaRad Ventura is equipped with the summer night ventilation function, which ventilates the room with cool outdoor air if the outdoor temperature is at least 2 degrees lower than the temperature in the room. If ‘cooling’ using outdoor air is required during summer nights, this function is an ideal solution. This unit has a high ventilation rate, meaning the cool air will be supplied to the room at higher speeds.

Functionality ClimaRad Ventura V1D

The ClimaRad Ventura V1D can ventilate two rooms simultaneously. It provides direct ventilation via the facade. Clean outdoor air is supplied and polluted air is exhausted outdoors. The unit is equipped with a heat exchanger that preheats the ‘clean air’. It uses the heat of the exhausted ‘polluted air’ to do so. The unit is equipped with a duct to an external room, where preheated air is supplied and polluted air is exhausted using a ventilation grille. Because this involves a single device for two rooms, it results in significant energy savings.

Functions ClimaRad Ventura V1D

  • Regulate indoor air quality
  • Filtering outside air
  • Decentralised ventilation
  • Summer night ventilation
  • Heat recovery
